CHT-VEGA
500MA ADJUSTABLE VOLTAGE REGULATOR
The CHT-VEGA is single chip, positive, adjustable linear voltage regulator with low drop-out. The output voltage can be adjusted by means of an external 2-resistor bridge. The CHT-VEGA is available in a tiny ceramic package TDFP-16 for applications where small PCB footprint is critical.
Key features
- Temperature range: -55°C to 225°C
- Input Voltage: 4.5V to 5.5V
- Output voltage: 1.2V to 3.3V (adjustable)
- Maximum Output current: 500mA
- Total precision (absolute + drift): +/-5%
- Over-current limitation
- Thermal protection: 300°C Typ.
- Quiescent current: 1mA
- Available packaging: TDFP16
Applications
Regulated power supply in down-hole, aerospace and industrial systems.
Ordering information
| Ordering reference | Description | Package | Status | Link |
| CHT-STA485302-D-T |
Positive Voltage Regulator, Vin= 5V, VOUTmin=1.2Volts, Imax=0.5A |
Known Good Die | Last Time Buy | Contact us |
| CHT-STA4853B-TDFP16-T |
Positive Voltage Regulator, Vin= 5V, VOUTmin=1.2Volts, Imax=0.5A |
TDFP16 | Last Time Buy | Contact us |
